Bucky Stand‑for LZX-7

Bucky stand side mount The LZX-7 side mount bucky stand is a vertical radiography equipment with electric fixed lifting column for X-ray examination.

It is suitable for radiography inspection of the human head, chest, abdomen, pelvis and other parts.

The device is composed of a column, a carriage, a bucky (a film cart that can be pulled out of the device in the box), a balance device, and other parts. It can be adapted to different sizes of ordinary X-ray film cassettes and CR IP boards, as well as DR flat panel detector.

Main technical parameters

1. The maximum travel of the bucky is 1300mm.
2. The width of the card slot is suitable for boards with a thickness of less than 19mm.
3. The highest point of the top edge of the bucky is 2050mm from the ground, and the lowest point is 750mm; the highest point of the bottom edge of the bucky is 1550mm from the ground, and the lowest point is 250mm. The center of the bucky (17″ × 17″) is 1800mm from the ground, and the lowest point is 500mm.
4. Suitable size of clip: 5″ × 7″ – 17″ × 17″.
5. Filter grid (optional): a. Grid density: 40 lines / cm; b. Grid ratio: 10: 1 c. Convergence distance: 180cm.

This side mount bucky stand is a reliable auxiliary device for X-ray radiography. Its flexible height movement and wide compatible size help medical teams complete different body parts imaging conveniently. The optional filter grid further improves image quality for clinical diagnosis. It is widely used in clinics and imaging rooms for daily radiographic work.
